Scuba Diving Applications

The High Pressure Oil-free Compressor has been developed for compressing and filling non-hazardous gases such as Nitrox and Oxygen into various size of cylinders under high pressure.

When coupled the Compressor with a PSA Oxygen Concentrator, a Portable Oxygen Fill System is formed. By using this system, you can generate and store oxygen whenever and wherever you like.

The filled oxygen cylinders are the best oxygen source for recharging Nitrox Scuba cylinders or Rebreather Oxygen Cylinders. By making and filling cylinders at your site, the uncertainty and logistics of delivered oxygen supplies are eliminated.

Compressor Features :

  1. Absolute dry, clean and oil-free.
  2. High Compression Ratio. Service pressure is up to 138 Bar(2000 psi/13.8MPa)
  3. Fast Filling. The fastest filling time of a M265 Cylinder is around 10 hours.
  4. Small and light weight, easy and safe to operate.
  5. Simple, reliable and easy maintenance.
  6. Energy Saving : Low power consumption.
  7. Cost-Effective.
  8. High Pressure Cylinder Storage saves cost of cylinders and storage space.

Compressor Specifications :

Model No. C150-500
Electrical Requirment

230V-AC, 50Hz or 115V-AC, 60Hz

Power Consumption 500W average
Inlet Pressure 6-20PSI (0.04-0.14MPa)
Max. Discharge Pressure 2000PSI (13.8MPa)
Flow Rate 5-10LPM
Machine Dimensions 38cm W x 62cm D x 63cm H
Net Weight 52.5kg
